1200Wh New Generation Portable Power Station
All around Portable Power Station
Ultra-Quite Mode
Super Quiet and Noiseless
Remote Control
APP Control
High-Power PV Input
PV 800W Fast Charging
Max. 1800W AC Input
Recharging to 90% in 1hr
Expandable Capacity
Max to 2060Wh
How Does M1200 Work ?
For Multiple Outdoor Applications, M1200 can supply power for a variety of scenarios.
Technical Specifications:
BATTERY INFO
Model: M1200
Capacity: 1030-2060Wh
Type: LiFePO4 (Lithium Iron Phosphate)
Life Cycles : 6000+ Cycles to 80% Original Capacity
Indicator : APP / TFT Screen
Storage Temp. : -50F-113F (-10C-45C)
Operating Temp. : -50F-104F (-10C-40C)
Material : ABS + PC + Metal
Weight : 13 kg
Dimensions : 400*195*200 mm
Battey Management System : OVP, UVPOCP, SCPOTP, UTP etc
Solar Charge System : MPPT Charge Controller
INPUT
AC : 1000W Max (220V-240V@60Hz) / 1000W Max (100V-120V@60Hz)
XT60 : 800W Max (Solar/DC 12-59V)
OUTPUT :
AC Grid : 1800W Max (220V-240V@60Hz) / 1200W Max (100V-120V@60Hz)
USB-A : 18W Max (5V-12V)
USB-C #1 : 100W Max
ISB-C #2 : 45W Max
DC 5525 : 120W (12V/10A)
Car Charger : 120W (12V/10A)
P1200 - Battery Expander
GENERAL
Capacity : 1030Wh
Cell Chemistry: LiFePO4 (Lithium Iron Phosphate)
Nominal Current : 23A
Lifecycle : 6000+ Cycles to 80% Capacity
Storage Temp. : -4F-113F (-20-45C)
Operating Temp. : 14F-113F (-10C-45C)
Material : ABS + PC + Metal
Weight : 13 kg
Dimensions : 400*195*200mm
Battery Management System : OVP, UVP, OCP, SCP, TOP, UTP, etc
INPUT
Battery Voltage Range: 42V-50.4V
Charge Voltage : 50.4V
Charge Current : 27A
OUTPUT
Discharge Current : 54A
DoD (Depth of Discharge) : 90%
